Dimensions
Product Specification
Available in multiple infill material Honeycomb and high density mineral wool to satisfy the requirement of both un-insulated and insulated doors.
SHEET THICKNESS | |||
---|---|---|---|
Gauge | 14 | 16 | 18 |
Millimeters | 2.0 | 1.6 | 1.2 |
TECHNICAL DATA FOR STANDARD FRAMES (D x H) | ||||
---|---|---|---|---|
Size of double rebate frame | (143 x 57 mm)* | |||
Size of single rebate frame | (100 x 57 mm) (100 x 70 mm) | |||
Frame assembly | Mitered | Butted | Welded |
Our fire doors have been tested in CBRI, Warrington, TBW, Underwriters laboratory for integrity, insulation and stability. Our commitment to quality and performance can be verified through a transparent online certification programme from Certifire warrington, or Underwriters laboratory. In addition our products are tested to IS 3614, BS 476 part 20 & 22 (ISO 834-1).
